Linx 4900 User Manual

Chapter 7: Diagnostics and Maintenance
MP65492–1 135 Linx 4900 Operating Manual
7.2.3 To View the System Configuration
You can view the system configuration information including the printhead
type, printer configuration and the current software version number at the
SYSTEM CONFIGURATION menu. To do this:
1. At the CURRENT MESSAGE screen, press the [F4] function key to
display the SETUP menu.
2. Select Diagnostics Menu > System Configuration.
The SYSTEM CONFIGURATION menu is displayed:
Figure 7-5 System Configuration Menu
With the exception of the Message Type option, this screen is for
viewing only; you cannot change any of the options.
This setting... Does this...
Head Type Indicates the type of printhead fitted
to the printer.
Message Type Allows you to display the MESSAGE
TYPE menu, which lists the available
message types. The example below
shows a sample of the message types
available for the Ultima printhead
with a 2-line Standard Speed (SS)
configuration:
Figure 7-6 Message Type Menu
Messages Stored Indicates the number of messages
currently stored.
>
49148
SYSTEM CONFIGURATION
Head Type
Message Type
Messages Stored
SW Links
SW Version
PCB Issue
Configuration
Language Group
: Ultima
: 26
: A
: v1.0.15
: 1
: SS
: Euro1
49013
MESSAGE TYPE
7 Quality
7 Flexible
16 Quality
16 Flexible
>
4900 Op Manual.book Page 135 Tuesday, September 9, 2003 12:32 PM
