Chapter 7: Diagnostics and Maintenance
Linx 4900 Operating Manual 136 MP65492–1
4. Press the [esc] key to exit.
7.2.4 To View the System Pressure Values
The PRESSURE REFS screen displays the key pressure values used by
the printer to maintain the correct ink viscosity, and the maximum
allowable system pressure.
To view the pressure values, do the following:
1. At the CURRENT MESSAGE screen, press the [F4] function key to
display the SETUP menu.
2. Select Diagnostics Menu > Ref Pressures.
The following PRESSURE REFS screen
appears.
Figure 7-7 Pressure Refs Screen
SW Links Indicates, where relevant, any
software links fitted.
SW Version Indicates the current software version
number.
PCB Issue Indicates the issue number of the main
processor PCB.
Configuration The printer configuration, for
example, SS is a Standard Speed
printer.
Language Group Indicates the name of the language
group installed.
This setting... Does this...
>
Printhead Ref
Solvent Add
Maximum Run
: 184
: 188
: 255
49230
PRESSURE REFS
