Chapter 4: Creating and Editing Messages

MP65492–1 69 Linx 4900 Operating Manual

The TIME menu is displayed.

Figure 4-21 Time Menu

4. At the TIME menu, press the Up [ ] or Down [ ] arrow key to

scroll to the format you want.

5. Press the [enter] key to select the format and return to the EDIT

MESSAGE screen:

Figure 4-22 Edit Message Screen: Time Field

NOTE: The current time is not displayed in the message until you

have finished editing the message and returned to the

CURRENT MESSAGE screen.

49309

TIME

hh:mm

hh:mmpm

hhmm

hhmmpm

hh (24h)

hh (12h)

49119

F1 : Size 7 FH (Caps)

F3 : Field Type

F2 : Bold Off

F4 : Save & Exit

EDIT MESSAGE : MESSAGE 1

Sell by dd mmm yy

BATCH 9999

hh:mm

LINX

4900 Op Manual.book Page 69 Tuesday, September 9, 2003 12:32 PM
