MacDon PW8 - Page 135

215575 119 Revision B
0DF'RQ3:
0DF'RQ3:

%
(
&
'
(
)
*
$
Figure 4.29: Header Configuration Menu on Header
Settings Page
3. Touch HEADER CONFIGURATION field (A). A dialog box
showing a list of predefined header configuration
profiles opens.
• If your MacDon header is already set up, it appears on
the header list. Touch MacDon header title (B) to
highlight the selection in blue, and then touch green
check mark (E) to continue.
• If only default header (D) is shown, touch ABC
button (C) and use the on-screen keyboard to enter the
MacDon header information. When complete, select
one of the following options to return to the HEADER
SETTINGS page:
– Green check mark (E) saves the settings
– Garbage can icon (F) deletes the highlighted header
from the list
– Red X (G) cancels the change(s)
AUTO HEADER HEIGHT CONTROL
