215575 164 Revision B
$
Figure 4.118: Header Settings
4. To specify the type of header installed on the combine,
touch HEADER TYPE field (A).
$
%
Figure 4.119: Header Type
5. A list of predefined header types appears.
• For a pick-up header, select PICK UP (A).
• Touch green check mark (B) to save your selection and
continue.
$
Figure 4.120: Header Settings
6. Make sure that HEADER HAS REEL ATTACHED green check
box (A) is checked.
AUTO HEADER HEIGHT CONTROL
