215575 48 Revision B
$
%
Figure 3.43: Coupler Storage Location
4. Position coupler (A) onto storage plate (B) on the combine.
$
Figure 3.44: Electrical Connector
5. Disconnect electrical connector (A) from the header.
$
%
Figure 3.45: Electrical Connector Storage
6. Place electrical connector (A) into storage cup (B) on the
combine.
OPERATION
