215575 65 Revision B
Figure 3.87: Feeder House Locks
1. Pull handle (A) on the the combine to raise hooks (B) on
both sides of the feeder house.
2. Start the engine.
Figure 3.88: Header on Combine
3. Drive the combine slowly up to the header until feeder
house saddle (A) is directly under header top beam (B).
4. Raise the feeder house to the lift header, ensuring that
feeder house saddle (A) is properly engaged with the
header frame.
OPERATION
