Minebea Intec X3 User Manual

Defining the scale interval (Cd002)
Defining the dead load (Cd003)
The "Cd" calibration menu flashes.
8. Press OK.
MAX.FSd (full scale deflection) appears on the display.
9. Press OK.
------.kg appears on the display.
10. Press to move the decimal point to the left by one decimal place.
-----.-kg appears on the display.
11. Press OK.
00300.0 kg appears on the display (the "3" flashes).
12. Press (3×) to select the "0" digit.
13. Press
to select another digit to the left.
14. Press (2×) to select the "2" digit.
15. Press
(5×) to select the weight unit and change it to "g" with .
16. Press OK.
Cd 002 appears on the display.
17. Press OK.
StEP appears on the display.
18. Press OK.
1 appears on the display.
19. Press to change the scale interval to "5" (0.5 g).
20. Press OK.
Cd 003 appears on the display.
21. Press OK.
dEAdLo appears on the display.
22. Press OK.
LoAd (dead load with empty scale) appears on the display.
23. Press to select the "mV/V" entry if necessary.
7 Getting started X3 Process Indicator PR 5410
Minebea Intec EN-131
