A digital filter can be switched on only with the measuring time set to <160 ms.
If no particularly frequent fluctuations are expected in ongoing operation, the following
settings are recommended:
[Measuretime]: <160 ms
[Digital filter]: aperiod.
[Fcut]: 2.00 Hz
[Fcut]
This line only is shown if the digital filter is switched on.
The smaller the cut-off frequency, the slower the measurement and the more stable the
measurement result.
The cut-off frequency can be specified for the low pass filter.
Valid range: 0.1…2.5 Hz.
The available options depend on the measuring time.
[W&M]
See Chapter 7.14.15.1.
If [OIML] was selected, the device needs to warm up for 30 seconds.
[Unbal. Check deviat.]
The plausibility check is activated when the average deviation is >0%. The average
deviation of the individual load cells is calculated.
Setting range: 0…100%.
[Standstill time]
The parameters [Standstill time] and [Standstill range]are used to define the stability of
the scale (stable balance).
The input for the parameter [Standstill time] is expressed in seconds.
Valid range: 0.00…2 s
If the tome is set to "0" there is no check. The standstill time must not be less than the
measuring time.
[Standstill range]
As long as the weight fluctuations remain within this range, the device is determined to
be stable.
The input for the parameter [Standstill range] is expressed in "d."
Valid range: 0.01…10.00 dc.
[Tare timeout]
Timeout for a tare/zeroset command that cannot be executed (e.g. due to mechanical
instability of the scale, incorrect filter setting, resolution too high, standstill condition too
strict).
The input is done as seconds.
Valid range: 0.0…<2.5>…25 s.
At 0.0 s taring is only carried out when the scale is already stable.
7 Getting started X3 Process Indicator PR 5410
Minebea Intec EN-225
