Description Data

Cable gauge

1.5 mm

Cable length Max.15 m

Block diagram RS-232

Note:

After 30 seconds without data exchange, RTS and TxD are switched off.

4 Device installation X3 Process Indicator PR 5410

Minebea Intec EN-37
