Specifications
Description Data
Connection D-SUB female connector, 26-pin
Output: Qty 5 digit BCD + preceding sign
Input: Qty 1 bit "DATA_IN"
Output level Shared emitter to ground, open collector
External supply U
DC
= +5 V…+24 V
Voltage drop Approx. 0.9 V
Output current Max. 50 mA
Enable input 5 V/24 V configurable via switch S101
@ 5 V active-high >3.1 V; active-low <1.5 V
@ 24 V active-high >16 V; active-low <10 V
Protection against incorrect polarity
Potential isolation No
Cable type Screened twisted pair (e.g. LifYCY 2x2x0.20)
Cable length max. 50 m screened
Accessories D-SUB male connector, 26-pin
Incl. shielded housings
X3 Process Indicator PR 5410 4 Device installation
EN-86 Minebea Intec
