Description Data
Potential isolation Yes, via optocoupler
Cable type Screened twisted pair (e.g. LifYCY 2x2x0.20)
Cable length max. 50 m screened
Scope of delivery D-Sub male connector, 37-pin
Incl. shielded housings
PR 5510/12 block diagram
An external power supply is required: I/O channels potential-free; no
shared reference
Outputs
Inputs
4 Device installation X3 Process Indicator PR 5410
Minebea Intec EN-93
