Digital inputs
Channel CH1 CH2 CH3-CH6
Assignment Tare/reset tare, po-
sitive flank
Print command, positive
flank
Not used
Digital outputs
Channel CH1 CH2 CH3 CH4 CH5 CH6 CH7-CH12
Assignment "Dim"
Weight is <0
or >Max.
Weight is
within
the zero-
setting
range.
Output limit
1
Output li-
mit 2
Gross weight
value is within
±¼ d of zero
Scale er-
ror (ADC
error)
Not used
Input circuitry
Contact input
① input
② screen
③ supply unit U
DC
= 24 V 0.5 A
X3 Process Indicator PR 5410 4 Device installation
EN-94 Minebea Intec
