Set ETH Function 8-85
iPASOLINK EX Advanced: SET NETWORK AND SYSTEM PROVISIONING GGS-000547-01E
5. When completed, click the OK button.
6. Information dialog box appears. Click the OK button to proceed.
Figure 8-119 Information Dialog Box
7. The ETH OAM Setting window updates the information. Verify the displayed
information.
Figure 8-120 ETH OAM Setting Window — Link OAM Tab
This step ends the procedure.
Remote DTE Information
Unidirectional (read only) Indicates the DTE information of the destination equipment.
Remote Loopback (read only)
Link Event (read only)
MAC Address (read only)
Table 8-21 Link OAM Setting Parameter
Parameter Value Description
