5-6 CONNECT CABLES
GGS-000546-01E iPASOLINK EX Advanced: INSTALLATION
3. Secure the Gland Nut:
Figure 5-8 Secure Bland Nut
CAUTION: In case using the thin cable, the Gland Nut may not stop and be secured at
the appropriate position if tightening it by force. Ensure that the barrel end does not
stick out of the gap at the Gland Nut end.
This step ends the procedure.
