NSK Megatorque PS Series User Manual

— 8-4 —
8.1.2. Function of Control Output
 You can set control output function, output logic and stability timer to the output ports. This
function permits you to change the preset input port function to other function, and to switch to
one of extended functions.
◊ You may set the same function to multiple output ports.
◊ When setting an output function that is not included in the shipping set, you can
interchange it with a preset function.
For example, you may integrate the DRDY and WRN outputs to the NRM output, or
integrate OTPA and OTPM outputs to increase the number of idle ports.
Table 8-3: Output ports of the CN2 connector and assigned function
Shipping set
Pin
No.
Port
No.
Signal
code
Logic
Signal name Function Logic (shipping set)
28 PO0 DRDY Positive
Driver Unit ready
Reports that the Driver Unit is
ready for operation.
(The output opens when the
Drover Unit is not ready or an
alarm occurs.)
Open: Alarm
Closed: Normal
29 PO1 WRN Negative
Warning Reports warning.
Open: Warning
Closed: Normal
30 PO2 OTPA Negative
Over travel limit,
+ direction
Over travel limit (software of
hardware), + direction limit
Open: + direction limit
activated.
Closed: Normal
31 PO3 OTMA Negative
Over travel limit,
– direction
Over travel limit (software of
hardware), – direction limit
Open: – direction limit
activated.
Closed: Normal
32 PO4 SVST Positive
Servo state Reports state of the servo.
Open: Servo is OFF.
Closed: Servo is ON.
33 PO5 BUSY Positive
In-operation Reports operation status.
Open: Idle
Closed: In operation
34 PO6 IPOS
Positive
Positioning complete
Reports conditions of position
error and positioning operation.
Open: Positioning is not
completed, or lost
commanded position
data.
Closed: In position and
holding commanded
position data.
35 PO7 NEARA Positive
Target proximity A
Reports the Motor is nearing to
the commanded position.
Open: Not in proximity
Closed: In proximity
！
Caution : If your System is custom made and has special Input/Output function,
follow its specification documents.
◊ Above function settings are the shipping set.
