NSK Megatorque PS Series User Manual

— 9-9 —
Ì P AO : Absolute Position Scale Offset
 Sets the offset value from the Motor home potion to the user home position.
◊ Refer to “6.2.3. Setting of Home Position” for details.
Category Parameter
Format
AO data
Data range 0 to 2 621 439 [pulse]
Shipping set 0
 The offset value is counted from the Motor Home position in the CW direction seen from the
Motor output axis, regardless of the setting of parameter DI (Direction inversion).
 The parameter AO is automatically set if the scale home position is defined in the following
manners. .
◊ Execution of the command AZ (Absolute zero position set)
◊ Completion of Home Return
P AQ: Absolute Positioning, User Scale
 Executes a optioning to the target position.
The target position is specified in the units of parameter QR (Dividing number, user scale).
◊ Refer to “6.3.1. Positioning Command” and “8.6.4. User Scale Positioning” for details.
Category Command
Format1
AQ data
: Positioning in shorter direction
Format 2
AQ data /PL
: Position in the plus direction
Format 3
AQ data /MI
: Positioning in the minus direction
Data range
0 to (QR – 1)
[360°/QR]
: Position data
Conditions to
be met
• The Motor servo is on.
• Not in the middle of operation caused by an internal command (positioning command,
jogging and Home Return).
• The Motor is not stopping because of alarm or warning
• The input STP (Stop) is not activated.
 In the shorter way positioning, the Motor moves in the following direction.
◊ In the shorter direction to the target position.
◊ When an off-limits area is specified by the parameters OTP and OTM (Software over
travel limit), the Motor rotes in the direction not to gets in the area, regardless of
moving distance.
 The monitor TQ (Tell position, QR unit) reads out the position in units of user position scale.
