— 9-83 —
P ZCS : Start Point of Zone C
This parameter sets the starting point of the zone C at where he output ZONEC (Zone C) closes.
◊ Refer to “8.3.1. In-zone Output: ZONEA, ZONEB, ZONEC” for details.
◊ The zone C starts from the setting of the parameter ZCS (Start point of zone C) in the
counting up direction (plus direction) of scale data and ends at the setting of the
parameter ZCE (End point of zone C).
Category Parameter
Format 1
ZCS data
Format 2
ZCS /ST
: Sets the current position to the start point of the zone C
Data range 0~2 621 439 [pulse]
Shipping set 0
Conditions to
be met
<In case of teaching by the ZCS/ST>
• Alarm A0 (Position sensor error) is not occurring.
• Alarm A1 (Absolute position error) is not occurring.
• Alarm A4 (Over speed) is not occurring.
P ZCE : End Point of Zone C
This parameter sets the end point of the zone C at where the output ZONEC (Zone C) opens.
◊ Refer to “8.3.1. In-zone Output: ZONEA, ZONEB, ZONEC” for details.
◊ The zone C starts from the setting of the parameter ZCS (Start point of zone C) in the
counting up direction (plus direction) of scale data and ends at the setting of the
parameter ZCE (End point of zone C).
Category Parameter
Format 1
ZCE data
Format 2
ZCE /ST
: Sets the current position to the end point of the zone C.
Data range 0 to 2 621 439 [pulse]
Shipping set 0
Conditions to
be met
<In case of teaching by the ZCE/ST>
• Alarm A0 (Position sensor error) is not occurring.
• Alarm A1 (Absolute position error) is not occurring.
• Alarm A4 (Over speed) is not occurring.
P ZCW: Zone C Width
This parameter sets the minimum outputting time of the output ZONEC (Zone C).
◊ Refer to “8.3.1. In-zone Output: ZONEA, ZONEB, ZONEC” for details.
◊ When the Motor passes a narrow zone in high speed, the time for outputting the
ZONEC signal gets shorter. The parameter ZCW is used for reliable detection of the
output signal.
Category Parameter
Format
ZCW data
Data range 0.0 to 10 000.0 [ms]
Shipping set 0.0
To Next Page
