— A-12 —
Backup of Parameter
Store the parameter settings of the Driver Unit as a text file.
1) Launch Hyper Terminal.
◊ There is the icon you have made in the menu [Start menu] → [Program] →
[Accessory] → [Communication] → [Hyper Terminal].
2) The parameter AO (Absolute position scale offset) that sets the Motor home position and the
parameter MM (Multi-line mode) that specifies the monitoring mode to the Handy Terminal will
not be backed up with the following procedures. Keep the copy as described below.
(1) Read out the parameter AO.
Copy the settings of each Motor because it individually differs because of the offset
value.
AO
AO123456
:_
A
?
ENT
O
(2) Monitor setting of the parameter MM.
AO123456
:?MM
MM1
:_
M
?
ENT
M
3) Perform capturing of text (Record of communication contents).
◊ [Push] → [Capture text]
◊ After inputting file name, click [Start] button and start capturing of text.
4) Execute the command TX0 (Parameter dump) and monitor the settings of the Driver Unit.
:
X0_
X
T
ENT
0
Input of the command TX0 starts high speed scrolling of screen.
The execution completes when scrolling stops.
5) Stop capturing text.
◊ [Push] → [Capture test] → [Quit]
6) Open the captured text by a text editor and delete
the line on which the command TX0 is inputted.
TX0
RE
KP1
CP0
MO
SI/SY
MM0
PG0.05
(snip)
MM1
WD
P0
Delete this line only.
