Table 1-2shows the maximum number of peripherals or peripheral channels per package type. Not all
peripherals are available at the same time. The maximum number of peripherals is also limited by the
device chosen as per Table 1-1.
ACMP (analog
comparator)
111111111————————
PLL Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
External osc Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Internal 1 MHz RC
oscillator
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
20-pin TSSOP Yes—Yes——————————————
32-pin LQFP Yes—Yes—YesYes—Yes—————————
48-pin LQFP Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
48-pin QFN YesYesYesYes—————————————
64-pin LQFP ————YesYesYesYesYesYesYesYesYesYesYesYesYes
100-pin LQFP —————————YesYesYesYesYesYesYesYes
KGD ——————————————Yes—Yes
Supply voltage 3.13 V – 5.5 V
Execution speed Static – 25 MHz
1
Not all peripherals are available in all package types
Table 1-2. Maximum Peripheral Availability per Package
Peripheral 20 TSSOP 32 LQFP 48 QFN 48 LQFP 64 LQFP 100 LQFP KGD (Die)
MSCAN — Yes — Yes Yes Yes Yes
SC I0 Yes Yes Yes Yes Yes Yes Yes
SCI1 — Yes Yes Yes Yes Yes Yes
SCI2 — — — Yes Yes Yes Yes
SPI0 Yes Yes Yes Yes Yes Yes Yes
SPI1 — — — Yes Yes Yes Yes
SPI2 — — — — Yes Yes Yes
Timer Channels 4 = 0 … 3 6 = 0 … 5 6 = 0 … 5 8 = 0 … 7 8 = 0 … 7 8 = 0 … 7 8 = 0 … 7
8-Bit PWM Channels 4 = 0 … 3 6 = 0 … 5 6 = 0 … 5 8 = 0 … 7 8 = 0 … 7 8 = 0 … 7 8 = 0 … 7
ADC channels 6 = 0 … 5 8 = 0 … 7 8 = 0 … 7 12 = 0 … 11 16 = 0 … 15 16 = 0 … 15 16 = 0 … 15
Table 1-1. MC9S12G-Family Overview
1
Feature
S12GN16
S12GNA16
S12GN32
S12GNA32
S12GN48
S12G48
S12GA48
S12G64
S12GA64
S12G96
S12GA96
S12G128
S12GA128
S12G192
S12GA192
S12G240
S12GA240
