NXP Semiconductors MC9S12G User Manual

Device Overview MC9S12G-Family
MC9S12G Family Reference Manual Rev.1.27
80 NXP Semiconductors
28 PT4 IOC4 — — — V
DDX
PERT/PPST Disabled
29 PT3 IOC3 — — — V
DDX
PERT/PPST Disabled
30 PT2 IOC2 — — — V
DDX
PERT/PPST Disabled
31 PT1 IOC1 IRQ
——V
DDX
PERT/PPST Disabled
32 PT0 IOC0 XIRQ
——V
DDX
PERT/PPST Disabled
33 PAD0 KWAD0 AN0 — — V
DDA
PER1AD/PPS1AD Disabled
34 PAD8 KWAD8 AN8 — — V
DDA
PER0AD/PPS0AD Disabled
35 PAD1 KWAD1 AN1 — — V
DDA
PER1AD/PPS1AD Disabled
36 PAD9 KWAD9 AN9 ACMPO — V
DDA
PER0ADPPS0AD Disabled
37 PAD2 KWAD2 AN2 — — V
DDA
PER1AD/PPS1AD Disabled
38 PAD10 KWAD10 AN10 ACMPP V
DDA
PER0AD/PPS0AD Disabled
39 PAD3 KWAD3 AN3 — — V
DDA
PER1AD/PPS1AD Disabled
40 PAD11 KWAD11 AN11 ACMPM V
DDA
PER0AD/PPS0AD Disabled
41 PAD4 KWAD4 AN4 — — V
DDA
PER1AD/PPS1AD Disabled
42 PAD12 KWAD12 — — — V
DDA
PER0AD/PPS0AD Disabled
43 PAD5 KWAD5 AN5 — — V
DDA
PER1AD/PPS1AD Disabled
44 PAD13 KWAD13 — — — V
DDA
PER0AD/PPS0AD Disabled
45 PAD6 KWAD6 AN6 — — V
DDA
PER1AD/PPS1AD Disabled
46 PAD14 KWAD14 — — — V
DDA
PER0AD/PPS0AD Disabled
47 PAD7 KWAD7 AN7 — — V
DDA
PER1AD/PPS1AD Disabled
48 PAD15 KWAD15 — — — V
DDA
PER0AD/PPS0AD Disabled
49VRH————— — —
50 VDDA — — — — — — —
51 VSSA — — — — — — —
52 PS0 RXD0 — — — V
DDX
PERS/PPSS Up
53 PS1 TXD0 — — — V
DDX
PERS/PPSS Up
54 PS2 RXD1 — — — V
DDX
PERS/PPSS Up
55 PS3 TXD1 — — — V
DDX
PERS/PPSS Up
56 PS4 MISO0 — — — V
DDX
PERS/PPSS Up
Table 1-17. 64-Pin LQFP Pinout for S12G48 and S12G64
Function
<----lowest-----PRIORITY-----highest---->
Power
Supply
Internal Pull
Resistor
Package Pin Pin
2nd
Func.
3rd
Func.
4th
Func
5th
Func
CTRL
Reset
State
