Device Overview MC9S12G-Family
MC9S12G Family Reference Manual Rev.1.27
34 NXP Semiconductors
• Interrupt flag register for pin interrupts on ports P, J and AD
• Control register to configure IRQ pin operation
• Routing register to support programmable signal redirection in 20 TSSOP only
• Routing register to support programmable signal redirection in 100 LQFP package only
• Package code register preset by factory related to package in use, writable once after reset. Also
includes bit to reprogram routing of API_EXTCLK in all packages.
• Control register for free-running clock outputs
•
1.3.5 Main External Oscillator (XOSCLCP)
• Loop control Pierce oscillator using a 4 MHz to 16 MHz crystal
— Current gain control on amplitude output
— Signal with low harmonic distortion
— Low power
— Good noise immunity
— Eliminates need for external current limiting resistor
— Transconductance sized for optimum start-up margin for typical crystals
— Oscillator pins can be shared w/ GPIO functionality
1.3.6 Internal RC Oscillator (IRC)
• Trimmable internal reference clock.
— Frequency: 1 MHz
— Trimmed accuracy over –40°C to +125°C ambient temperature range:
1.0% for temperature option C and V (see Table A-4)
1.3% for temperature option M (see Table A-4)
1.3.7 Internal Phase-Locked Loop (IPLL)
• Phase-locked-loop clock frequency multiplier
— No external components required
— Reference divider and multiplier allow large variety of clock rates
— Automatic bandwidth control mode for low-jitter operation
— Automatic frequency lock detector
— Configurable option to spread spectrum for reduced EMC radiation (frequency modulation)
— Reference clock sources:
– External 4–16 MHz resonator/crystal (XOSCLCP)
– Internal 1 MHz RC oscillator (IRC)
