Timer Module (TIM16B8CV3)
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 763
The TIM16B8CV3 could use up to 11 interrupt vectors. The interrupt vector offsets and interrupt numbers
are chip dependent.
23.6.1 Channel [7:0] Interrupt (C[7:0]F)
This active high outputs will be asserted by the module to request a timer channel 7 – 0 interrupt. The TIM
block only generates the interrupt and does not service it. Only bits related to implemented channels are
valid.
23.6.2 Pulse Accumulator Input Interrupt (PAOVI)
This active high output will be asserted by the module to request a timer pulse accumulator input interrupt.
The TIM block only generates the interrupt and does not service it.
23.6.3 Pulse Accumulator Overflow Interrupt (PAOVF)
This active high output will be asserted by the module to request a timer pulse accumulator overflow
interrupt. The TIM block only generates the interrupt and does not service it.
23.6.4 Timer Overflow Interrupt (TOF)
This active high output will be asserted by the module to request a timer overflow interrupt. The TIM block
only generates the interrupt and does not service it.
Table 23-25. TIM16B8CV3 Interrupts
Interrupt Offset Vector Priority Source Description
C[7:0]F — — — Timer Channel 7–0 Active high timer channel interrupts 7–0
PAOVI — — — Pulse Accumulator
Input
Active high pulse accumulator input interrupt
PAOVF — — — Pulse Accumulator
Overflow
Pulse accumulator overflow interrupt
TOF — — — Timer Overflow Timer Overflow interrupt
