NXP Semiconductors MC9S12G - Features

Device Overview MC9S12G-Family
MC9S12G Family Reference Manual Rev.1.27
30 NXP Semiconductors
The MC9S12G-Family is optimized for lower program memory sizes down to 16k. In order to simplify
customer use it features an EEPROM with a small 4 bytes erase sector size.
The MC9S12G-Family deliver all the advantages and efficiencies of a 16-bit MCU while retaining the low
cost, power consumption, EMC, and code-size efficiency advantages currently enjoyed by users of NXP’s
existing 8-bit and 16-bit MCU families. Like the MC9S12XS-Family, the MC9S12G-Family run 16-bit
wide accesses without wait states for all peripherals and memories. The MC9S12G-Family is available in
100-pin LQFP, 64-pin LQFP, 48-pin LQFP/QFN, 32-pin LQFP and 20-pin TSSOP package options and
aims to maximize the amount of functionality especially for the lower pin count packages. In addition to
the I/O ports available in each module, further I/O ports are available with interrupt capability allowing
wake-up from stop or wait modes.
1.2 Features
This section describes the key features of the MC9S12G-Family.
1.2.1 MC9S12G-Family Comparison
Table 1-1 provides a summary of different members of the MC9S12G-Family and their features. This
information is intended to provide an understanding of the range of functionality offered by this
microcontroller family.
Table 1-1. MC9S12G-Family Overview
1
Feature
S12GN16 S12GNA16 S12GN32 S12GNA32 S12GN48 S12G48 S12GA48 S12G64 S12GA64 S12G96 S12GA96 S12G128 S12GA128 S12G192 S12GA192 S12G240 S12GA240
CPU CPU12V1
Flash memory
[kBytes]
16 16 32 32 48 48 48 64 64 96 96 128 128 192 192 240 240
EEPROM [kBytes] 0.5 0.5 1 1 1.5 1.5 1.5 2233444444
RAM [kBytes] 112244444888811111111
MSCAN ————— 111111111111
SCI 11112222233333333
SPI 11112222233333333
16-Bit Timer
channels
66666666688888888
8-Bit PWM channels66666666688888888
10-Bit ADC channels 8 — 8 — 12 12 — 12 — 12 — 12 — 16 — 16 —
12-Bit ADC channels — 8 — 8 — — 12 — 12 — 12 — 12 — 16 — 16
Temperature Sensor——————————————Yes—Yes
RVA ——————————————YES—YES
8-Bit DAC —————————————— 2 — 2
