S12 Clock, Reset and Power Management Unit (S12CPMU)
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 355
• Autonomous periodical interrupt (API)
• Bus Clock Generator
— Clock switch to select either PLLCLK or external crystal/resonator based Bus Clock
— PLLCLK divider to adjust system speed
• System Reset generation from the following possible sources:
— Power-on reset (POR)
— Low-voltage reset (LVR)
— Illegal address access
— COP time out
— Loss of oscillation (clock monitor fail)
— External pin RESET
10.1.2 Modes of Operation
This subsection lists and briefly describes all operating modes supported by the S12CPMU.
10.1.2.1 Run Mode
The voltage regulator is in Full Performance Mode (FPM).
The Phase Locked Loop (PLL) is on.
The Internal Reference Clock (IRC1M) is on.
The API is available.
• PLL Engaged Internal (PEI)
— This is the default mode after System Reset and Power-On Reset.
— The Bus Clock is based on the PLLCLK.
— After reset the PLL is configured for 50 MHz VCOCLK operation
Post divider is 0x03, so PLLCLK is VCOCLK divided by 4, that is 12.5MHz and Bus Clock is
6.25MHz.
The PLL can be re-configured for other bus frequencies.
— The reference clock for the PLL (REFCLK) is based on internal reference clock IRC1M
• PLL Engaged External (PEE)
— The Bus Clock is based n the PLLCLK.
— This mode can be entered from default mode PEI by performing the following steps:
– Configure the PLL for desired bus frequency.
– Program the reference divider (REFDIV[3:0] bits) to divide down oscillator frequency if
necessary.
– Enable the external oscillator (OSCE bit)
– Wait for oscillator to start up (UPOSC=1) and PLL to lock (LOCK=1).
• PLL Bypassed External (PBE)
