Table 1-34. Reset Sources and Vector Locations
1.12.2 Interrupt Vectors
Table 1-35 lists all interrupt sources and vectors in the default order of priority. The interrupt module (see
Chapter 6, “Interrupt Module (S12SINTV1)”) provides an interrupt vector base register (IVBR) to relocate
the vectors.
Vector Address Reset Source
CCR
Mask
Local Enable
$FFFE Power-On Reset (POR) None None
$FFFE Low Voltage Reset (LVR) None None
$FFFE External pin RESET
None None
$FFFE Illegal Address Reset None None
$FFFC Clock monitor reset None OSCE Bit in CPMUOSC register
$FFFA COP watchdog reset None CR[2:0] in CPMUCOP register
Table 1-35. Interrupt Vector Locations (Sheet 1 of 2)
Vector Address
1
Interrupt Source
CCR
Mask
Local Enable
Wake up
from STOP
Wakeup
from WAIT
Vector base + $F8 Unimplemented instruction trap None None - -
Vector base+ $F6 SWI None None - -
Vector base+ $F4 XIRQ X Bit None Yes Yes
Vector base+ $F2 IRQ
I bit IRQCR (IRQEN) Yes Yes
Vector base+ $F0 RTI time-out interrupt I bit CPMUINT (RTIE)
10.6 Interrupts
Vector base+ $EE TIM timer channel 0 I bit TIE (C0I) No Yes
Vector base + $EC TIM timer channel 1 I bit TIE (C1I) No Yes
Vector base+ $EA TIM timer channel 2 I bit TIE (C2I) No Yes
Vector base+ $E8 TIM timer channel 3 I bit TIE (C3I) No Yes
Vector base+ $E6 TIM timer channel 4 I bit TIE (C4I) No Yes
Vector base+ $E4 TIM timer channel 5 I bit TIE (C5I) No Yes
Vector base + $E2 TIM timer channel 6 I bit TIE (C6I) No Yes
Vector base+ $E0 TIM timer channel 7 I bit TIE (C7I) No Yes
Vector base+ $DE TIM timer overflow I bit TSCR2 (TOI) No Yes
Vector base+ $DC TIM Pulse accumulator A overflow
2
I bit PACTL (PAOVI) No Yes
Vector base + $DA TIM Pulse accumulator input edge
3
I bit PACTL (PAI) No Yes
Vector base + $D8 SPI0 I bit SPI0CR1 (SPIE, SPTIE) No Yes
Vector base+ $D6 SCI0 I bit SCI0CR2
(TIE, TCIE, RIE, ILIE)
Yes Yes
Vector base + $D4 SCI1 I bit SCI1CR2
(TIE, TCIE, RIE, ILIE)
Yes Yes
