Analog-to-Digital Converter (ADC12B8CV2)
MC9S12G Family Reference Manual Rev.1.27
450 NXP Semiconductors
12.3.2.12.2 Right Justified Result Data (DJM=1)
Table 12-22 shows how depending on the A/D resolution the conversion result is transferred to the ATD
result registers for right justified data. Compare is always done using all 12 bits of both the conversion
result and the compare value in ATDDRn.
Module Base +
0x0010 = ATDDR0, 0x0012 = ATDDR1, 0x0014 = ATDDR2, 0x0016 = ATDDR3
0x0018 = ATDDR4, 0x001A = ATDDR5, 0x001C = ATDDR6, 0x001E = ATDDR7
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R 0 000
Result-Bit[11:0]
W
Reset0000000000000000
= Unimplemented or Reserved
Figure 12-15. Right justified ATD conversion result register (ATDDRn)
Table 12-22. Conversion result mapping to ATDDRn
A/D
resolution
DJM conversion result mapping to
ATDDRn
8-bit data 1 Result-Bit[7:0] = result,
Result-Bit[11:8]=0000
10-bit data 1 Result-Bit[9:0] = result,
Result-Bit[11:10]=00
12-bit data 1 Result-Bit[11:0] = result
