NXP Semiconductors MC9S12G User Manual

Analog-to-Digital Converter (ADC10B12CV2)
MC9S12G Family Reference Manual Rev.1.27
470 NXP Semiconductors
Table 13-15. Analog Input Channel Select Coding
SC CD CC CB CA
Analog Input
Channel
00000 AN0
0001 AN1
0010 AN2
0011 AN3
0100 AN4
0101 AN5
0110 AN6
0111 AN7
1000 AN8
1001 AN9
1010 AN10
1011 AN11
1100 AN11
1101 AN11
1110 AN11
1111 AN11
10000 Internal_6,
0 0 0 1 Internal_7
0 0 1 0 Internal_0
0 0 1 1 Internal_1
0100 VRH
0101 VRL
0110 (VRH+VRL) / 2
0111 Reserved
1 0 0 0 Internal_2
1 0 0 1 Internal_3
1 0 1 0 Internal_4
1 0 1 1 Internal_5
11XX Reserved
