Analog-to-Digital Converter (ADC12B12CV2)
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 503
14.3.2.12.2 Right Justified Result Data (DJM=1)
Table 14-22 shows how depending on the A/D resolution the conversion result is transferred to the ATD
result registers for right justified data. Compare is always done using all 12 bits of both the conversion
result and the compare value in ATDDRn.
Module Base +
0x0010 = ATDDR0, 0x0012 = ATDDR1, 0x0014 = ATDDR2, 0x0016 = ATDDR3
0x0018 = ATDDR4, 0x001A = ATDDR5, 0x001C = ATDDR6, 0x001E = ATDDR7
0x0020 = ATDDR8, 0x0022 = ATDDR9, 0x0024 = ATDDR10, 0x0026 = ATDDR11
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R 0 000
Result-Bit[11:0]
W
Reset0000000000000000
= Unimplemented or Reserved
Figure 14-15. Right justified ATD conversion result register (ATDDRn)
Table 14-22. Conversion result mapping to ATDDRn
A/D
resolution
DJM conversion result mapping to
ATDDRn
8-bit data 1 Result-Bit[11:8]=0000,
Result-Bit[7:0] = conversion result
10-bit data 1 Result-Bit[11:10]=00,
Result-Bit[9:0] = conversion result
12-bit data 1 Result-Bit[11:0] = result
