Timer Module (TIM16B8CV3)
MC9S12G Family Reference Manual Rev.1.27
746 NXP Semiconductors
The 16-bit main timer is an up counter.
A full access for the counter register should take place in one clock cycle. A separate read/write for high
byte and low byte will give a different result than accessing them as a word.
Read: Anytime
Write: Has no meaning or effect in the normal mode; only writable in special modes (test_mode = 1).
The period of the first count after a write to the TCNT registers may be a different size because the write
is not synchronized with the prescaler clock.
23.3.2.6 Timer System Control Register 1 (TSCR1)
Read: Anytime
Write: Anytime
Module Base + 0x0005
76543210
R
TCNT7 TCNT6 TCNT5 TCNT4 TCNT3 TCNT2 TCNT1 TCNT0
W
Reset00000000
Figure 23-11. Timer Count Register Low (TCNTL)
Module Base + 0x0006
76543210
R
TEN TSWAI TSFRZ TFFCA PRNT
000
W
Reset00000000
= Unimplemented or Reserved
Figure 23-12. Timer System Control Register 1 (TSCR1)
Table 23-6. TSCR1 Field Descriptions
Field Description
7
TEN
Timer Enable
0 Disables the main timer, including the counter. Can be used for reducing power consumption.
1 Allows the timer to function normally.
If for any reason the timer is not active, there is no 64 clock for the pulse accumulator because the 64 is
generated by the timer prescaler.
6
TSWAI
Timer Module Stops While in Wait
0 Allows the timer module to continue running during wait.
1 Disables the timer module when the MCU is in the wait mode. Timer interrupts cannot be used to get the MCU
out of wait.
TSWAI also affects pulse accumulator.
