Device Overview MC9S12G-Family
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 77
31 PAD3 KWAD3 AN3 — — V
DDA
PER1AD/PPS1AD Disabled
32 PAD11 KWAD11 AN11 ACMPM V
DDA
PER0AD/PPS0AD Disabled
33 PAD4 KWAD4 AN4 — — V
DDA
PER1AD/PPS1AD Disabled
34 PAD5 KWAD5 AN5 — — V
DDA
PER1AD/PPS0AD Disabled
35 PAD6 KWAD6 AN6 — — V
DDA
PER1AD/PPS1AD Disabled
36 PAD7 KWAD7 AN7 — — V
DDA
PER1AD/PPS1AD Disabled
37 VDDA VRH — — — — — —
38 VSSA — — — — — — —
39 PS0 RXD0 — — — V
DDX
PERS/PPSS Up
40 PS1 TXD0 — — — V
DDX
PERS/PPSS Up
41 PS2 RXD1 — — — V
DDX
PERS/PPSS Up
42 PS3 TXD1 — — — V
DDX
PERS/PPSS Up
43 PS4 MISO0 — — — V
DDX
PERS/PPSS Up
44 PS5 MOSI0 — — — V
DDX
PERS/PPSS Up
45 PS6 SCK0 — — — V
DDX
PERS/PPSS Up
46 PS7 API_EXTC
LK
ECLK SS0
—V
DDX
PERS/PPSS Up
47 PM0 RXCAN — — — V
DDX
PERM/PPSM Disabled
48 PM1 TXCAN — — — V
DDX
PERM/PPSM Disabled
1
The regular I/O characteristics (see Section A.2, “I/O Characteristics”) apply if the EXTAL/XTAL function is disabled
Table 1-16. 48-Pin LQFP Pinout for S12G48 and S12G64
Function
<----lowest-----PRIORITY-----highest---->
Power
Supply
Internal Pull
Resistor
Package Pin Pin
2nd
Func.
3rd
Func.
4th
Func
5th
Func
CTRL
Reset
State
