NXP Semiconductors MC9S12G User Manual

32 KByte Flash Module (S12FTMRG32K1V1)
MC9S12G Family Reference Manual Rev.1.27
838 NXP Semiconductors
25.3.2.17 Flash Reserved5 Register (FRSV5)
This Flash register is reserved for factory testing.
All bits in the FRSV5 register read 0 and are not writable.
25.3.2.18 Flash Reserved6 Register (FRSV6)
This Flash register is reserved for factory testing.
All bits in the FRSV6 register read 0 and are not writable.
25.3.2.19 Flash Reserved7 Register (FRSV7)
This Flash register is reserved for factory testing.
Table 25-25. FOPT Field Descriptions
Field Description
7–0
NV[7:0]
Nonvolatile Bits — The NV[7:0] bits are available as nonvolatile bits. Refer to the device user guide for proper
use of the NV bits.
Offset Module Base + 0x0011
76543210
R00000000
W
Reset00000000
= Unimplemented or Reserved
Figure 25-23. Flash Reserved5 Register (FRSV5)
Offset Module Base + 0x0012
76543210
R00000000
W
Reset00000000
= Unimplemented or Reserved
Figure 25-24. Flash Reserved6 Register (FRSV6)
