48 KByte Flash Module (S12FTMRG48K1V1)
MC9S12G Family Reference Manual Rev.1.27
904 NXP Semiconductors
26.4.6.7 Erase All Blocks Command
The Erase All Blocks operation will erase the entire P-Flash and EEPROM memory space.
Upon clearing CCIF to launch the Erase All Blocks command, the Memory Controller will erase the entire
Flash memory space and verify that it is erased. If the Memory Controller verifies that the entire Flash
memory space was properly erased, security will be released. During the execution of this command
(CCIF=0) the user must not write to any Flash module register. The CCIF flag will set after the Erase All
Blocks operation has completed.
26.4.6.8 Erase Flash Block Command
The Erase Flash Block operation will erase all addresses in a P-Flash or EEPROM block.
Table 26-43. Program Once Command Error Handling
Register Error Bit Error Condition
FSTAT
ACCERR
Set if CCOBIX[2:0] != 101 at command launch
Set if command not available in current mode (see Table 26-27)
Set if an invalid phrase index is supplied
Set if the requested phrase has already been programmed
1
1
If a Program Once phrase is initially programmed to 0xFFFF_FFFF_FFFF_FFFF, the Program Once command will
be allowed to execute again on that same phrase.
FPVIOL None
MGSTAT1 Set if any errors have been encountered during the verify operation
MGSTAT0
Set if any non-correctable errors have been encountered during the verify
operation
Table 26-44. Erase All Blocks Command FCCOB Requirements
CCOBIX[2:0] FCCOB Parameters
000 0x08 Not required
Table 26-45. Erase All Blocks Command Error Handling
Register Error Bit Error Condition
FSTAT
ACCERR
Set if CCOBIX[2:0] != 000 at command launch
Set if command not available in current mode (see Table 26-27)
FPVIOL Set if any area of the P-Flash or EEPROM memory is protected
MGSTAT1 Set if any errors have been encountered during the verify operation
MGSTAT0
Set if any non-correctable errors have been encountered during the verify
operation
