4535 612 10261 HD11 Service Manual Page 161
CSIP Level 1 Adjustments: Introduction
7 Adjustments
Introduction
This section contains information for adjusting the system monitor. Except for the monitor,
there are no other calibration or alignment adjustments to make in the field for this system.
Except for the monitor, there are no other voltage adjustments to make in the field for this sys-
tem.
NOTE The procedures in this section should only be performed by qualified technicians who
have been trained by Philips to maintain HD11 systems.
Adjusting the
Monitor
This section contains instructions for performing adjustments to a monitor in the field. These
instructions assume that system power is switched on.
The four buttons on the bottom, right-front of the monitor not only adjust video brightness and
contrast within the range established via system setups (see “To set the monitor BRIGHTNESS
and CONTRAST range” on page 162), but are also the means of accessing and navigating the
on-screen display (OSD), which is used to set monitor parameters.
When the two right buttons are pressed simultaneously as the monitor powers up, the OSD
Main Menu (Figure 7-1) is available.
Pressing the two right buttons together also degausses the CRT.
