Philips HD11 - Parts Table Part Numbers; Parts List; Table 14-1 HD11 Ultrasound System Parts List

4535 612 10261 HD11 Service Manual Page 387
CSIP Level 1 Parts: Parts Table Part Numbers
Parts Table
Part Numbers
Included in the tables that follow are two columns of part numbers. Some parts have numbers
listed in both columns. This is required due to varying SAP clients located in various geographical
locations. If there is only one number on the line item you are looking for, then that is the num-
ber you use. Refer to Parts Table Definitions for Legacy/12NC part number information.
Parts List
Table 14-1 HD11 Ultrasound System Parts List
Item
No.
Located
On
Legacy
Part Number
12NC
Part Number Part Description Notes/Reference
1 Figure 14-9
453561172621
1
Backing, Soft key Control panel Soft key
assembly
2 Figure 14-17
453563494481
1
Bezel CW Used for the Non-imaging
module (E-box
453561194871)
3 Figure 14-17
453563494461
1
Bezel, Honda, Convex Used for the cartridge
connector module
453561194861
See Table 14-2 for option
kits
4 Figure 14-17
453563494471
1
Bezel, Perfect Union Used for the Explora
module 453561194851
5 Figure 14-9 453561153391 Bezel, Soft key Control panel Soft key
assembly
