4535 612 10261 HD11 Service Manual Page 317
CSIP Level 1 Configuration: Primary PCB Information
Figure 13-1 Primary System PCB Names and Locations (PC)
Compatibility
Information
Hauppauge Video Capture PCB
Serial Interface card
TVIEW Gold Video Converter PCB
E-box Interface PCB
Sound Card
See Figure 13-4
Motherboard PCB
See Figure 13-8
See Figure 13-7
See Figure 13-6
See Figure 13-9
See Figure 13-10
PC rear connector names and locations
See Figure 11-8
Graphics PCB
See Figure 13-5
