4535 612 10261 HD11 Service Manual Page 192
CSIP Level 1 Disassembly and Reassembly: Disassembly Procedures
Figure 10-5 Removing the Front Panel
Torx screws (6 plcs)
6
7
6. Remove the six Torx screws securing
the front panel enclosure.
7. Pull the panel straight out from the
front of the system. Proceed to
step 8.
To Next Page
