4535 612 10261 HD11 Service Manual Page 282
CSIP Level 1 Disassembly and Reassembly: Disassembly Procedures
Figure 10-95 Placing the First Corrugated Wrap
23. Place all boxed manuals, cables, and
other items around the system on
the pallet.
NOTE If the system is being shipped
with an external VCR or
printer, place it at the front of
the system under the monitor
mount.
24. Fit the first tri-fold corrugated wrap
into the retainers at the outside edge
of the pallet.
NOTE Printed side of the corrugated
wrap faces outward.
Proceed to step 25.
