4535 612 10261 HD11 Service Manual Page 343
CSIP Level 1 Configuration: Peripheral Settings
B&W Printer
The Sony UP-D895MD has DIP switches on the back of the printer. The Philips-recommended
DIP switch settings for use with the HD11 system are given in Table 13-3.
Color Printer
There are no field-accessible settings on the UP-D23MD that FSEs need to access. The only dif-
ference between the UP-D23MD and the UP-D21MD used on the EnVisor is that the
UP-D23MD supports “high-speed” USB 2.0. The settings in the supporting drivers for these
printers are the same.
VCR
The VCR has front/rear panel switches, interface adapter PCB switch settings, displayed menu
settings, and hidden menu settings. Mitsubishi HS-MD3000U/E VCR settings for use with the
HD11 are given in Table 13-4, Table 13-5, and Table 13-6.
The RS-232 interface adapter is installed inside the VCR rear panel (Figure 13-22 and
Figure 13-23). Switches on the interface adapter must be set correctly for proper operation.
NOTE All switches and internal menus settings should be set properly at the factory on VCRs
shipped with new systems. However, when a replacement VCR is ordered, you will
need to check the switch settings and menu settings
To check or reset the switches, remove the two screws securing the adapter, remove the
adapter, and verify that the switches are set as indicated in Table 13-4.
Table 13-3 UP-D895MD B&W Printer Settings
Rear of Printer
DIP Switches 1–5 Down
DIP Switch 6 Up
DIP Switches 7–12 Down
