4535 612 10261 HD11 Service Manual Page 337
CSIP Level 1 Configuration: Disk Drive Settings
CD Drive
Jumpers
Figure 13-21 shows typical CD-RW drive jumper positions. Set the jumper to the MASTER posi-
tion on the secondary IDE.
Figure 13-21 CD-RW Drive Jumper Position
MOD Drive
Jumpers
Set the MOD drive jumpers to SLAVE on the secondary IDE.
