4535 612 10261 HD11 Service Manual Page 336
CSIP Level 1 Configuration: Disk Drive Settings
Disk Drive
Settings
The jumper positions and switch settings of the drives in the HD11 depend on the manufacturer
of the drives.
Hard Disk Drive
Jumpers
Figure 13-20 shows typical hard disk drive jumper positions. Examine the drive itself for informa-
tion on the correct settings. The hard disk drive is the only device on the primary IDE, and is
usually set to MASTER or SINGLE.
Figure 13-20 Hard Disk Drive Jumper Settings
