4535 612 10261 HD11 Service Manual Page 292
CSIP Level 1 Cabling: Cable Table Part Numbers
Cable Table
Part Numbers
Included in the tables that follow are two columns of cable part numbers. Some cables have num-
bers listed in both columns. This is required due to varying SAP clients located in various geo-
graphical locations. If there is only one number on the line item you are looking for, then that is
the number you use. Refer to Parts Table Definitions for Legacy/12NC part number information.
Cable Parts
List
Table 11-1 HD11 System Signal Interconnect Cables
Item
No.
Legacy
Part Number
12NC
Part Number Cable Description Notes/Reference
1 M2540-69200 453563468691 Cable Assy, Audio In/Out Not Shown
2 453561152771 Cable Assy, External I/O USB
(Extension)
System Diagram: Figure 11-1
3 M2540-69050 No part number
as of 1/20/05
Cable Assy, Keyboard Aux Power Cable Illustration: Figure 11-16
System Diagram: Figure 11-1
4 M2540-69080 453563470861 Cable Assy, LAN, External, 10-ft For external connections
Included in the accessory box
shipped with the system,
Figure 14-31
System Diagram: Figure 11-1
5 M2540-69130 453563470901 Cable Assy, LAN, Internal System Diagram: Figure 11-1
6 M2540-69030 453563468661 Cable Assy, Physio Trigger Part of PC assembly (Internal)
System Diagram: Figure 11-3
See Table 14-2 for option kits
To Next Page
