4535 612 10261 HD11 Service Manual Page 60
CSIP Level 1 Safety: Symbols
The following symbols are used inside the system:
Phone line jack
Universal Serial Bus (USB) connection
Ethernet connection
Identifies high-voltage components.
Identifies the point where the safety system ground is fastened to
the chassis.
