Chapter 4: Management with WebPAM PROe
141
To create a new disk array:
1. Click the Subsystem icon in Tree View.
2. Click the Disk Arrays icon.
3. Click the Create tab in Management View.
4. From the Create tab dropdown menu, choose Express.
5. Check the boxes to choose any one or combination of:
Redundancy – The array will remain available if a physical drive fails
Capacity – The greatest possible amount of data capacity
Performance – The highest possible read/write speed
Spare Drive – A hot spare drive is created when you select
Redundancy, Spare Drive and five or more unconfigured physical drives
are available
Mixing SATA/SAS Drive – Check this box if you want to use both SATA
and SAS drives in the same disk array
If the box is unchecked, and you have both SATA and SAS drives,
different arrays will be created for each type of drive.
6. In the Number of Logical Drives field, enter the number of logical drives you
want to make from this disk array.
7. From the Application Type menu, choose an application that best describes
your intended use for this disk array:
8. Click the Update button.
Or check the Automatic Update box and updates will occur automatically.
The following parameters display:
Disk Arrays – The number of physical drives in the disk array, their slot
numbers, configurable capacity, and the number of logical drives to be
created
Logical Drives – The slot number of the logical drive(s), their RAID
level, capacity, and stripe size
Spare Drives – The physical drive slot number of the dedicated hot
spare assigned to this disk array (all RAID levels except RAID 0)
If you accept these parameters, proceed to the next step.
If you do NOT accept these parameters, review and modify your selections
in the previous steps.
9. When you are done, click the Submit button.
File Server
Video Stream
Transaction Data
Transaction Log
•Other
