VTrak E-Class Product Manual
158
LUN Mapping Parameters
• Initiator Name
• Fibre Channel – A Fibre Channel initiator name is the World Wide Port
Name of the device and is composed of a series of eight, two-digit
hexadecimal numbers.
• SAS – A SAS initiator name is the SAS address of the HBA card in the
Host PC.
• Symbolic Name – Optional. A common name for a Fibre Channel initiator
• Port ID – Port ID of the Fibre Channel port for this initiator
• LUN – Logical Unit Number on this logical drive for the selected initiator. You
must enter a different LUN for each logical drive
Notes
• Obtain the initiator name from the initiator utility on your Host
PC.
• The initiator name you input must match exactly in order for
the connection to work.
