VTrak E-Class Product Manual
14
Figure 2. Rack mount assembly diagram
Inside of post
Rack front post
Rail attaching screws
(not included)
Alignment pins
two on each flange
Inside of post
Rack rear post
Front rail
Rear rail
Support for
subsystem
Note that only the front rail has a support for the subsystem.
