RL78/G15 CHAPTER 4 PORT FUNCTIONS

R01UH0959EJ0110 Rev.1.10 Page 106 of 765

Mar 7, 2023

20-pin products

Symbol 7 6 5 4 3 2 1 0 Address After reset R/W

P0 P07 P06 P05 P04 P03 P02 P01 P00 FFF00H 00H (output latch) R/W

P2 0 0 0 0 P23 P22 P21 P20 FFF02H 00H (output latch) R/W

P4 0 0 0 0 0 0 P41 P40 FFF04H 00H (output latch) R/W

P12 0 0 P125 0 0 P122 P121 0 FFF0CH 00H (output latch) R/W

P13 P137 0 0 0 0 0 0 0 FFF0DH Undefined R

Pmn Output data control (in output mode) Input data read (in input mode)

0 Output 0 Input low level

1 Output 1 Input high level

Remark m = 0, 2, 4, 12, 13

n = 0 to 7

Caution Be sure to set bits that are not mounted to their initial values.
