RL78/G15 CHAPTER 4 PORT FUNCTIONS

R01UH0959EJ0110 Rev.1.10 Page 112 of 765

Mar 7, 2023

8-pin products

Bit Function Setting value

0 1

PIOR02 TI01/TO01 P04 P40

PIOR00 TI00 P137 P03

PIOR32 VCOUT0 P40 P125

10-pin products

Bit Function Setting value

0 1

PIOR00 TI00 P137 P03

PIOR32 VCOUT0 P02 P125

PIOR30 PCLBUZ0 P02 P40

Bit Function Setting value

00 01 10 11

PIOR03 PIOR02 TI01/TO01 P04 P40 P02 Setting prohibited
