RL78/G15 CHAPTER 4 PORT FUNCTIONS

R01UH0959EJ0110 Rev.1.10 Page 113 of 765

Mar 7, 2023

16-pin products

Bit Function Setting value

0 1

PIOR06 TO03 P41 P07

PIOR00 TI00 P137 P03

PIOR14 SCLA0 P06 P00

SDAA0 P07 P01

PIOR12 SCK01/SCL01 P07 P00

SI01/SDA01 P06 P01

SO01 P05 P02

PIOR26 INTP6 P00 P05

PIOR24 INTP5 P01 P07

PIOR23 INTP4 P03 P41

PIOR22 INTP3 P04 P121

PIOR21 INTP2 P40 P122

PIOR34 INTP7 P02 P06

PIOR32 VCOUT0 P02 P125

Bit Function Setting value

00 01 10 11

PIOR05 PIOR04 TI02/TO02 P05 P01 P41 Setting prohibited

PIOR03 PIOR02 TI01/TO01 P04 P40 P02 Setting prohibited

PIOR11 PIOR10 SCK00/SCL00 P02 P06 P05 Setting prohibited

SI00/RxD0/SDA00 P01 P05 P04 Setting prohibited

SO00/TxD0 P00 P04 P03 Setting prohibited

PIOR31 PIOR30 PCLBUZ0 P02 P40 P06 Setting prohibited
