RL78/G15 CHAPTER 4 PORT FUNCTIONS
R01UH0959EJ0110 Rev.1.10 Page 114 of 765
Mar 7, 2023
20-pin products
Bit Function Setting value
0 1
PIOR14 SCLA0 P06 P00
SDAA0 P07 P01
PIOR23 INTP4 P03 P41
PIOR22 INTP3 P04 P121
PIOR21 INTP2 P40 P122
PIOR20 INTP1 P125 P20
PIOR33 VCOUT1 P41 P125
PIOR32 VCOUT0 P02 P125
Bit Function Setting value
00 01 10 11
PIOR07 PIOR06 TI03 P41 P41 P20 Setting prohibited
TO03 P41 P07 P20
PIOR05 PIOR04 TI02/TO02 P05 P01 P41 Setting prohibited
PIOR03 PIOR02 TI01/TO01 P04 P40 P02 Setting prohibited
PIOR01 PIOR00 TI00 P137 P03 P20 Setting prohibited
TO00 P03 P03 P21
PIOR13 PIOR12 SCK01 P07 P00 P20 P07
SCL01 P07 P00 P20 P23
SI01 P06 P01 P125 P06
SDA01 P06 P01 P41 P22
SO01 P05 P02 P41 P05
PIOR11 PIOR10 SCK00/SCL00 P02 P06 P05 Setting prohibited
SI00/RxD0/SDA00 P01 P05 P04 Setting prohibited
SO00/TxD0 P00 P04 P03 Setting prohibited
PIOR27 PIOR26 INTP6 P00 P05 P23 Setting prohibited
PIOR25 PIOR24 INTP5 P01 P07 P22 Setting prohibited
PIOR35 PIOR34 INTP7 P02 P06 P21 Setting prohibited
PIOR31 PIOR30 PCLBUZ0 P02 P40 P06 Setting prohibited
Caution Be sure to set bits that are not mounted to their initial values.
